IRF7457 , IRF7457TRPBF , 7457 , N-Channel 20 V 15A (Ta) 2.5W (Ta) Surface Mount 8-SO
Kategori
Stok Kodu
11-5144
1,08 USD + KDV
49,22 TL
Kalan Stok : 25
IRF7457 , IRF7457TRPBF , 7457 , N-Channel 20 V 15A (Ta) 2.5W (Ta) Surface Mount 8-SO
|
Mfr
|
|
|
|
Series
|
|
|
|
Packaging
|
Tube
|
|
|
Part Status
|
Obsolete
|
|
|
FET Type
|
|
|
|
Technology
|
|
|
|
Drain to Source Voltage (Vdss)
|
20 V
|
|
|
Current - Continuous Drain (Id) @ 25°C
|
|
|
|
Drive Voltage (Max Rds On, Min Rds On)
|
4.5V, 10V
|
|
|
Rds On (Max) @ Id, Vgs
|
7mOhm @ 15A, 10V
|
|
|
Vgs(th) (Max) @ Id
|
3V @ 250µA
|
|
|
Gate Charge (Qg) (Max) @ Vgs
|
42 nC @ 4.5 V
|
|
|
Vgs (Max)
|
±20V
|
|
|
Input Capacitance (Ciss) (Max) @ Vds
|
3100 pF @ 10 V
|
|
|
FET Feature
|
-
|
|
|
Power Dissipation (Max)
|
2.5W (Ta)
|
|
|
Operating Temperature
|
-55°C ~ 150°C (TJ)
|
|
|
Mounting Type
|
Surface Mount
|
|
|
Supplier Device Package
|
8-SO
|
|
|
Package / Case
|
