IRF7465 , IRF7465TRPBF , 7465 , N-Channel 150 V 1.9A (Ta) 2.5W (Ta) Surface Mount 8-SO
Kategori
Stok Kodu
11-5152
0,90 USD + KDV
38,46 TL
Kalan Stok : 40
IRF7465 , IRF7465TRPBF , 7465 , N-Channel 150 V 1.9A (Ta) 2.5W (Ta) Surface Mount 8-SO
|
Mfr
|
|
|
|
Series
|
|
|
|
Packaging
|
Tube
|
|
|
Part Status
|
Obsolete
|
|
|
FET Type
|
|
|
|
Technology
|
|
|
|
Drain to Source Voltage (Vdss)
|
150 V
|
|
|
Current - Continuous Drain (Id) @ 25°C
|
|
|
|
Drive Voltage (Max Rds On, Min Rds On)
|
10V
|
|
|
Rds On (Max) @ Id, Vgs
|
280mOhm @ 1.14A, 10V
|
|
|
Vgs(th) (Max) @ Id
|
5.5V @ 250µA
|
|
|
Gate Charge (Qg) (Max) @ Vgs
|
15 nC @ 10 V
|
|
|
Vgs (Max)
|
±30V
|
|
|
Input Capacitance (Ciss) (Max) @ Vds
|
330 pF @ 25 V
|
|
|
FET Feature
|
-
|
|
|
Power Dissipation (Max)
|
2.5W (Ta)
|
|
|
Operating Temperature
|
-55°C ~ 150°C (TJ)
|
|
|
Mounting Type
|
Surface Mount
|
|
|
Supplier Device Package
|
8-SO
|
|
|
Package / Case
|
